Daewoo DWD-E1211R’S - Specification

31
Dimension (mm)
Unit Weight (kg)
Maximum Mass of Dry Cloth
Standard Water Consumption
Spin Speed (RPM)
Operating Water Pressure
630 x 750 x 930 (WxDxH)
80(Net) / 88(Gross)
Wash: 10Kg (Dry: 6Kg)
130 l
No Spin/400/600/800/1000/1200
0.03MPa ~ 0.8MPa (0.3kgf/cm
2
~ 8kgf/cm
2
)
MODEL DWD-E1211R’S DWD-E1211W’S
SPECIFICATION
WIRING DIAGRAM
DWD-E1211R’S
DWD-E1211W’S
