10
DIRECTION FOR DISASSEMBLY
HEATER AND THERMISTOR
1 Separate the plate t as from the washer.
(Remove two screws at rear)
2 Separate the case detergent as and remove two
screws from panel f.
3 Separate the panel f as from the washer. 4 Separate the cabinet front from the washer.
(Remove the clamp door as and 4 screws)
5 Separate connectors from the heater and remove the
nut by using a box wrench.
6 Remove the earth terminal and loosen the nut by using
a box wrench.
7 Pull out the heater from the tub.
To Next Page
