HOW TO REROUTE THE DRAIN HOSE (ONLY xE MODEL)
1
Loosen the back cover
screws on the rear side of
the washer, and detach the
back cover.
2
Detach the outside drain
hose with widening hose
clamp.
3
Detach the fixing band by
hand.
4
Detach the inside drain
hose fixing screw with
O
±
driver.
5
Detach the drain hole
cover of the hoping
direction.
6
Move the drain hose to the
direction to be changed,
and attach the fixing band.
7
Insert the inside drain
hose, and the fasten the
fixing screw tightly.
8
Insert the outside drain
hose together with the
hose-fixing clamp.
9
Attach the detached back
cover again, and insert the
detached drain-hole-cover
instead of the original one.
HOW TO USE THE DRAIN HOSE(ONLY xE MODEL)
INSTALLING DRAIN HOSE
Widen the drain clip and insert the drain
hose into the drain tap together with drain
hose. Dipping the end of the drain hose in
warm water makes easy to insert the drain
hose.
HOW TO USE IN WINTER
1
Insert the drain hose
into the drain tap.
2
Secure the hose clip
around the end of the
drain hose.
• In case that it goes over a doorsil
water flow will be restricted if any
portion of the drain hose is
raised more than 20 cm from the
ground.
• In case that it is connected when
the drain hose is extended, it
may not exceed 3 meters.
• Take care the end of the drain
hose. Do not sink the end of the
drain hose.
•
To avoid the washing machine’s being frozen.
- Remove the inside water of the washing machine completely.
- Remove the inside water of the inlet-hose and drain hose completely.
•
In case of being frozen.
- Dip the detached inlet-hose in the hot water (about 50°C) (* Don’t use
above 50°C surely)
- Leave the tub alone for 10 minutes with poruing the hot water. (about
50 °C)
- Check the drain and inlet’s operation after attaching the inlet-hose.
20cm
3m
