39
PARTS DIAGRAM
NO. PARTS NAME PARTS CODE SPECIFICATION REMARK
B09 CABINET 3610808011 PAINTING(0.6)
B10 LEG FIX 3617702300 THERMAL PLASTIC ELASTOMER
B11 BASE U 3610310200 PP 200W
3610312200 PP 260W
B12 LEG ADJUST 3617702010 PP
B13 COVER UNDER 3611402711 PP
B14 COVER PUMP 3611405320 PP(B360F)
3611405301 UL/CSZ(466FWU, HFH-400)
B15 SCREW TAPPING 7112501611 T1 TRS 5*16 MFZN
B16 MOTOR SHADED POLE 3618957200 230-240V/50HZ L=1350 VSF
3618957230 220V/50HZ L=1350 VSF
3618957260 220V/60HZ L=1350 VSF
3618957300 110-127V/60HZ L=1350 VSF
B17 FILTER AS 3611901530 DWF-5591 DPNF E-TYPE
C01 BALANCER AS 3616105400 100'S, HIDDEN
C02 FILTER AS 3611904700 100'S LINT FILTER AS
C03 FRAME FALL 3612202900 PP
C04 TUB 3618815300 SUS
C05 GUIDE FILTER AS 3612507210 HIDDEN FILTER(SUS 0.6T)
C06 SPECIAL BOLT 3616008600 SUS
C07 SPECIAL SCREW 3616003700 SUS 5.5*16
C08 SPECIAL NUT 3616008700 SUS
C09 SPECIAL SCREW 3616003700 SUS 5.5*16
C10 TUB U 3618815201 FRPP-M/B 200W
3618815501 FRPP-M/B 260W
C11 SPECIAL NUT 4507D83080 SUS 304
C12 FLANGE TUB 3617201200 10KG 3-FOOT 200W
3617200200 ALDC12 260W
C13 SPECIAL SCREW 3616007000 SCM 24H, 6.5*24
C14 CAP PULSATOR 3610911200 PP
C15 SPECIAL SCREW 3616003720 SUS 6*26.5
C16 PULSATOR AS 3619705510 100M
D01 COVER TUB O 3611417700 PP, 100M 200W
3611413900 PP 260W
D02 TUB O 3618807100 1098 NON PUMP
D03 HOSE AS 3613200781 L=1350MM OPTION
D04 SUSPENSION AS(B) 3619805400 100C'S ROD=592 SPR=102 200W
3619803900 DWF-1398,BLACK,BACK 260W
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
