CIRCUIT DIAGRAM
NO. PARTS NAME PARTS CODE SPECIFICATION REMARK
D05 SUSPENSION AS(F) 3619805500 100C'S ROD=592 SPR=112 200W
3619803800 DWF-1398,YELLOW,FRONT 260W
D06 HOSE OVERFLOW 3613208901 PELD, L=280MM NON PUMP
D07 VALVE DRAIN AS 3615408400 1098'S, VE TYPE NON PUMP
D08 HOSE DRAIN I AS 3613218500 LDPE+EVA, L=219.5 NON PUMP
HOSE DRAIN I 3613217700 PELD, L=219.5 PUMP
D09 BASE 3610387400 SECEN 2.0T
D10 SPECIAL SCREW 3616006900 SCM 24H, 6.5*18
D11 SPECIAL SCREW 3616007000 SCM 24H, 6.5*24
D12 INNER EARTH WIRE 3612712200 GN VSF(30/0.18)
HARNESS EARTH WIRE 3612713150 VSF YW/GN L1=620 L2=200
D13 MOTOR SYNCHRONOUS 3966010430 220-240V/50, 60HZ, 23, 1806
3966320810 110-127V/50, 60HZ, 23, 1806
3618957640 110V/60HZ, 23, 1806 260WTC
D14 GEAR MECHANISM 3617307610 GM-1300-KS6P0 200W
3617308310 GM-2000-KS6P2 260W
D15 BOLT HEX 7341801511 6B-1 8*15 MFZN4
D16 PROTECTOR GEAR 3618301300 SBHG 1.6T
D17 BELT V 3616590220 M20.5, AGING 60HZ
3616590230 M21, AGING 50HZ
D19 CUSHION DOWN 3611502700 POM(8MM)
D20 MOTOR CONDENSER 3964221231 110-127V 60HZ, W1S50CA011
3964510430 220-240V 50HZ, W1D50VA011
3964321261 220V 60HZ, W1D50UA014
3964821320 120-127V/60HZ, W1D50JA001
3964221020 110V 60HZ, WM244EA011 260WTC
D21 BOLT HEX 7650802528 6B-1 8*25 PW(3*28) MFZN
D22 PULLEY MOTOR AS 3618432000 M-TYPE DS=10 DP=48.5 60HZ
3618431900 M-TYPE DS=10 DP=53 50HZ
3618403510 ADC-12 DS=12 DP=52.5 60HZ 260WTC
D23 BODY BUBBLE AS 3610402921 100M, 200M, HOSE=1580MM 200W
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
