THE REPAIR METHOD
18
No. Process Notice
Disassemble 2
5
6
7
8
Disassemble the pulley
Disassemble the clutch
boss assembly
Separate coupling from
clutch boss ass’y
Cleaning
Catch the boss and pull
upward with spiral rotate in
the clockwise direction.
Clean the drum plate, coupling
surface and contact face
between drum plate and
coupling.
It is necessary to keep cotton
piece goods being dry and
clean.
