Daewoo DWF-178W - The Process of Disassemble

THE REPAIR METHOD
17
No. Process Notice
Disassemble 1
1
2
3
4
Release screws marked 4-point
Remove the protector
Remove the v-belt
Loosen the fastening nut
Disassemble the spring
washer
Use wrench or driver.
- ratchet handle
- extension bar
- socket : 10mm
Use fixing jig for pulley as
to see fig 1.
and 17mm-socket for nut.
Take out plain washer if it has.
THE PROCESS OF DISASSEMBLE
