13
DIRECTIONS
To assemble the gear mechanism ass’y, reverse the disassembly procedure.
NOTES
⑦
Remove the tub I ass’y.
⑪
Remove four special bolt of gear mechanism ass’y by
Pull out the gear mechanism ass’y.
using a box wrentch.
⑧
Lay the front of the washer on the floor.
⑨
Remove four special bolts of gear protect by using a box
wrentch and remove gear protect.
⑩
Remove the V-belt.
⑫
To Next Page
