PARTS DIAGRAM
Parts List
NO. PART NAME PART CODE SPECIFICATION REMARK
B01 CABINET 3610809600 PAINTED STEEL SHEET 0.6T
B02 HANDLE CABINET 3612603300 PP
B03 PLATE UPPER 3614521600 PP
B04 BASE U 3610389100 PP LOW H=45 DWF-760/810
3610389200 PP HIGH H=135 DWF-762/812
3610389000 PP - JAPAN DWF-761/811
B05 LEG ADJUST AS 3617702120 SCREW(4*14)
B06 LEG FIX 3617703000 SBR
B07 HOLDER SUPPORT F 3613044600 FRPP(GF30%) FRONT
B08 HOLDER SUPPORT B 3613044500 FRPP(GF30%) REAR
B09 COVER BACK 3611413600 SPG 0.4T
B10 COVER UNDER 3611418500 PP OPTION
B11 HARNESS OUTER 3610068700 50/0.18GREEN ST710489-2 2-WIRE POWER CORD
B12 HOSE DRAIN O AS 3613218100 LDPE L=833 NON-PUMP, JAPAN
3613226600 L=950mm, HANGER NON-PUMP
B13 HOSE DRAIN O AS 3613218800 LDPE/EVA L=1600 PUMP PUMP
B14 GUIDE DRAIN HOSE 3612502300 PP
B15 FILTER AS 3611904900 DWF-800WNP E-TYPE
3611904910 DWF-800WNP E-TYPE AUSTRALIA
B16 UNIT DRAIN PUMP 3618962300 110V/60Hz,67872,800W PLASET
3618962200 220V/60Hz,67876,800W
3618962400 220-240V/50Hz,67869,800W
3618959100 110-120V/60Hz ASKOLL
3618959000 220V/60Hz
3618958900 220-240V/50Hz
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
