40
PARTS DIAGRAM
Parts List
NO. PART NAME PART CODE SPECIFICATION REMARK
C01 BALANCER AS 3616104700 DWF-6010 STAINLESS STEEL
C02 TUB I 3618808501 SUS 0.5T
C03 TUB U 3618808601 PP
C04 GUIDE FILTER AS 3612507000 DWF-6010NP
C05 SPECIAL SCREW 3616003700 SUS 5.5X16
C06 PULSATOR AS 3719706700 DWF-800WNP
C07 BALANCER AS 3616104500 DWF-5510PN PLASTIC
C08 TUB I 3618808100 PP
C09 GUIDE FILTER 3612503900 PP
C10 PULSATOR AS 3619706600 DWF-750WTP
C11 FILTER AS 4505E82002 POLYESTER 90X120 INSERT
C12 SPECIAL SCREW 3616002901 SUS 304 NON-SILOCK
C13 SPECIAL NUT 4507D83080 SUS 304
C14 FLANGE TUB 3617201100 5KG 3-FOOT
C15 SPECIAL SCREW 3616007000 SCM24H, 6.5x24
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
