PARTS DIAGRAM
󱇧󱇧
Parts List
NO. PART NAME PART CODE SPECIFICATION REMARK
D01 COVER TUB O 3611414600 PP ONLY JAPAN
3611418400 PP
D02 TUB O 3618807600 PP ONLY JAPAN
3618817600 PP
D03 SUSPENSION AS F 3619804200 FRONT
D04 SUSPENSION AS B 3619804300 REAR
D05 VALVE DRAIN AS 3615408500 DWF-750M NON-PUMP
D06 HOSE DRAIN I AS 3613227010 EVA 100%
36100AAA00 EVA 100% DWF-801WJC W;59g ONLY JAPAN
D07 HOSE DRAIN I AS 3613226900 LDPE+EVA DWF-800WNP PUMP
D08 CLAMP 4507D08150 MFZN HOSE ID=7PIE OPTION : PUMP
D09 HOSE 4500D08210 ID=4.0
D10 CLAMP 4507D08150 MFZN HOSE ID=7PIE OPTION : BUBBLE
D11 HOSE 4500D08210 ID=4.0
D12 BASE 3610302900 SECEN 1.2T
D13 SPECIAL SCREW 3616007000 SCM24H 6.5X24
D14 MOTOR SYNCHRONOUS 3618958750 220-240V/50,60Hz KD-DW22LH
3618958720 100-130V/50,60Hz KD-DW11LF
D15 GEAR MECHANISM 3617307310 GM-0600-KJ4P0
D16 BOLT HEX 7341801511 6B-1 8X15 MFZN
D17 PROTECTOR GEAR 3618303600 SGCC 1.2T
D18 SPECIAL WASHER 4505E34030 PP
D19 UNIT MOTOR AS 3618959800 W1S30BC003, AC 100/50,60Hz
3618959900 W1S30CC004, 110-120V/60Hz
3618960201 W1S30VC005, 220-240V/50,60Hz
D20 BOLT HEX 7650802511 6B-1 8X25 HS MFZN
D21 PULLEY MOTOR 3618401490 M-TYPE DS=10 DP=53 50Hz PRESS PULLEY
3618401480 M-TYPE DS=10 DP=48.5 60Hz
D22 WASHER SPRING 7401008011 SW-8 MFZN
D23 NUT HEX 7392800011 M8XP1.25 MFZN
D24 BELT V 3616590210 M20, AGING 50Hz
3616590200 M19.5, AGING 60Hz
D25
HARNESS EARTH INNER 3612757010 L=560
✔ Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
