TROUBLE SHOOTING

assy panel

NO. PART NAME PART CORD SPECIFICATION Q’TY REMARKS

P01 KNOB 3613403700 ABS 4.0000

P02 SCREW TAPPING 7122401411 T2S TRS 4X14 MFZN 3.0000

P03 PANEL B 3614234400 PP 1.0000

P04 HOSE SPRAY 3613201210 LEPE 1.0000

P05 LEVER W.S SELECT 3613702000 PP 1.0000

P06 BRACKET PANEL 3610605500 PP 1.0000

P07 SCREW TAPPING 7122401411 T2S TRS 4X14 MFZN 2.0000

P08 SWITCH DRAIN 3619043700 VP531A-2H, 250VAC/15A 1.0000

P09 TIMER WASH 3619910940

S-K80NT, SAN, 2SELECT, CONN

1.0000

P10 LEVER CONTROL 3613701400 DWM-3000, POM 2.0000

P11 TIMER SPIN 3619911000 S-800CA, SAN, CONN 1.0000

P12 LINK VALVE 3617804000 PP BAND 1.0000

P13 S/W COVER 3619044800 LIP TYPE 1.0000

P14 SWITCH DRAIN 3619043700 VP531A-2H, 250VAC/15A 1.0000 PUMP

P15 HARNESS DRAIN 3612787400 MSF20/0.18 CONN+187FLAG 1.0000 PUMP

assy accessory

NO. PART NAME PART CORD SPECIFICATION Q’TY REMARKS

A01 COVER SAFETY 3611418900 PE-LD 1.0000

A02 LEG 3617702400 PP 4.0000

A03 SCREW TAPPING 7122401411 T2S TRS 4X14 MFZN 4.0000

A04 HOSE DRAIN O AS 3613224310 L=820MM, NON-CLAMP 1.0000

A05 CLAMP HOSE O 3611202400 HSW-3, 4.0KG 1.0000 PUMP

A06 HOSE DRAIN O 3613222600 4010NP 1.0000 PUMP

A07 GUIDE DRAIN HOSE 3612502300 PP 1.0000 PUMP

✔ Caution:

In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the

latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
