PCB ASS’Y

assy tub

NO. PART NAME PART CORD SPECIFICATION Q’TY REMARKS

T01 BASE WATER SUPPLY 3610389500 PP 1.0000

T02 FILTER OVER FLOW 3611903700 PP 1.0000

T03 FILTER AS 3611904000 PP+POLYESTER 1.0000

T04 RING BASKET 3614602300 PP 1.0000

T05 SCREW TAPPING 7122401411 T2S TRS 4*14 MFZN 2.0000

T06 BASKET SPIN 3619103300 DWM-800C 1.0000

T07 LINK BRAKE 3617801600 PP BAND W6 1.0000

T08 SPRING COVER 3615110400 HSW3 1.0000

T09 DOOR SPIN O 3611797800 PP 1.0000

T10 COVER INNER 3611418800 PP 1.0000

T11 PLATE T 3614522500 PP 1.0000

T12 BELLOWS AS 3616401800 AS, 800C 1.0000

T13 FIXTURE BELLOWS 3612005000 PP 1.0000

T14 GUIDE CASCADE 3612509000 PP 1.0000

T15 SPECIAL SCREW 3616002901 SUS604 (NON SILOCK) 1.0000

T16 PULSATOR AS 3619706500 800C 1.0000

T17 CAP SCREW 3610911700 PP 2.0000

T18 TUB 3618817900 PP (JI-360) 1.0000

T19 ROD VALVE 3618504000 PE-HD 1.0000

T20 BELLOWS VALVE 4505C06040 NR 1.0000

T21 VALVE CAP 4505F06013 PE-HD 1.0000

T22 SPRING VALVE 4505C06022 SWC WR 1.0D 1.0000

T23 CASE VALVE

3611131500 PP 1.0000 NON-PUMP

3611131600 PP 1.0000 PUMP

T24 INLET JOINT 3617504100 PP 1.0000

T25 HOSE OVERFLOW 3613220800 LDPE 1.0000 JAPAN

T26 PROTECTOR F.B 3618303500 NBR 1.0000 PUMP

T27 GEAR HOUSING AS 3617306200 DWF-7510S R=3.3:1 1.0000

T28 SPECIAL BOLT 3616008400 M6 SIDE-FIXING 1.0000

T29 PULLEY PULSATOR 3618432200 FR-PP GP-2300 1.0000

T30 SCREW TAPPING 7122502011 T2S TRS 5X20 MFZN 5.0000

T31 RING O 4506H05050 N. B. R 1.0000

T32 DOOR WASH 3611797900 PP 1.0000

✔ Caution:

In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the

latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
