WIRING DIAGRAM

NO. PART NAME PART CORD SPECIFICATION Q’TY REMARKS

M28 SPRING CUSHION 3615111900 HSW-3 3.0000

M29 DAMPER 3616900501 NBR 3.0000

M30 STOPPER LOWER 3615201300 PP 3.0000

3611330800 N LFC-3R, 3X0.75, 2.3M, GY 1.0000

3611330900 H H05VV-F 3X1.0 2.6M WH 1.0000

3611331000 RW-300/500, 3X0.75, 2.3M 1.0000

3611331100 - VCTF, 3X0.75, 2.3M 1.0000

3611331200 R VCTF, 2X1.25, 2.3M, GY 1.0000

3611331300 U VDFT, 3X0.75, 2.3M, GY 1.0000

M31 CORD POWER AS

3611331400 - H05VV-F, 3X0.75, 2.3M, GY 1.0000

3611331500 P VDFT, 3X0.75, 2.3M, GY 1.0000

3611331600 - H05VV-F, 3X0.75, 2.3M, BK 1.0000

3611331700 A-VCTFK, 2X0.75, 2.3M GY 1.0000

3611331800 F H05VV, 3X0.75, 2.3M, BK 1.0000

3611331900 N LFC-3R 3X0.75, 2.3M, GY 1.0000

3611332000 Z H05VV-F, 3X0.75, 2.3M, BK 1.0000

3611332100 T VCTFK, 2X0.75, 2.3M GY 1.0000

M32 HOSE DRAIN I 3613226400 LD-PE 1.0000

M33 UNIT DRAIN PUMP

3618958300

ASK0LL 220~240V/50HZ-TWIN

1.0000 NP, MP

3618958700

ASK0LL 110~120V/60HZ-TWIN

1.0000 TP

M34 HARNESS PUMP 3612787600

MSF20/0.18 2P+250FLAG L=500

1.0000

M35 FIXTURE PUMP 3612005500 PP 1.0000

M36 SCREW TAPPING 7122402011 T2S TRS 4X20 MFZN 1.0000

M37 WASHER PLAIN 7400108411 PW-1-8.4 MFZN 1.0000

✔ Caution:

In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the

latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
