WIRING DIAGRAM

assy main

NO. PART NAME PART CORD SPECIFICATION Q’TY REMARKS

M01 BELT V 4504B00020 M-25 1.0000

M02 WASHER SPRING 7501008011 SW-8 MFZN 1.0000

M03 NUT HEX 7392800011 M8*01.25 MFZN 1.0000

M04 PULLEY MOTOR AS

3618431600

PRESS(SGCC1.2T, D31), 4.3MM

1.0000

3618431700

PRESS(SGCC1.2T, D31), 2.1MM

1.0000

M05 SPECIAL SCREW 3616017010 T2 TRS 4X35 MFZN PW 3.0000

3618958100

220~240V/50HZ, W1D35VD050

1.0000 N, NP, M, MP

3618959200 AC 220V/60HZ, WD35UD050 1.0000 L

M06 MOTOR-WA AS 3618959300 AC 110V/60HZ, W1D35ED050 1.0000 T, TP

3618959400

AC 100V, 50/60HZ, W1D35BD050

1.0000 J

3618959600

110/240V, 5/60HZ, W1D35GD050

1.0000 S, D

M07 CUSHION MOTOR 3611554500 NR 3.0000

M08 CUSHION MOTOR SPOT 3611554600 PP 1.0000

3618948200 9.7/5.2uF, 400/440, CON-4P 1.0000 N, NP, M

M09 UNIT CAPACITOR

3618948300 10.4/5.2uF, 400/440, CON-4P 1.0000 MP

3618948500 45.6/20.8uF, 200/250, CON-4P 1.0000 T, TP

3618948600 45.6/25uF, 200/200, CON-4P 1.0000 J

M10 CAPACITOR WASH 4509C11020 20.8uF*2,200V 1.0000 S, D

M11 CAPACITOR SPIN

450E111060 16uF, 250V 1.0000 S

4509C11010 20.8uF, 200V 1.0000 D

M12 HARNESS CAPACITOR 3612706710 CONN A,B 1.0000 S, D

3612757000

4010DUAL NON-PUMP HARNESS

1.0000 S, D

M13 HARNESS AS

3612757220 DWM-500M, S/NON-PUMP 1.0000 N, M, T, L

3612757230 JAPAN, FILTER 1.0000 J

3612757300

4010SINGLE PUMP HARNESS

1.0000 NP, MP, TP

M14 BASE 3610389400 PP (JI-360) 1.0000

M15 COVER BACK 3611416610 PP (J740) 1.0000

M16 BOLT 7342602011 6B-2-6X20 POINTING MFZN 1.0000

M17 NUT HEX 7392600011 6N-2-6 MFZN 1.0000

M18 COUPLING DRUM 3619400300 AL 1.0000

M19 BOLT HEX 7341500811 6B-1-5X8 MFZN 3.0000

M20 SPRING BRAKE LEVER 3615109000 SWC D1.0 ZN8-C 1.0000

M21 PLATE BRAKE AS 3614517400 ASS’Y, 4.0KG 1.0000

M22 ASSY BRAKE WIRE 3619201702 SUS WIRE+PE L260 1.0000

M23 SCREW TAPPTITE 7272400811 TT3 TRS 4X8 MFZN 1.0000

M24

HARNESS EARTH MOTOR

3612756000 4010 S-MOTOR L=450 1.0000

3618947000 220V, 60HZ, W1D25UE040 1.0000 L

3618947100

220-240V, 50HZ, W1D25VE040

1.0000 N, NP, M, MP

M25 UNIT MOTOR SPIN

3618947200

120-240V, 60HZ, W1D25LE040

1.0000 S

3618947300

110-220V, 50HZ, W1D25FE040

1.0000 D

3618947500 110V, 60HZ, W1D25EE040 1.0000 T, TP

3618947600

100V, 50/60HZ, W1D25BE040

1.0000 J

M26 SCREW TAPPING 7122401611 T2S TRS 4X16 MFZN 3.0000

M27 STOPPER UPPER 3615201400 PP 3.0000

✔ Caution:

In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the

latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
