5) APPLICATION (MAIN PCB)
5.1- GENERAL: MICOM 26 port - 0V
5.2- DELETE J2 (CHANGING R OFF POINT 1DEG UP) : MICOM 26 port – 2.5V
LOW COOLING
OPTION
a. R-SENSOR OFF POINT ADJUSTMENT (1 DEG. DOWN)
b. J1 DELETION on LOW COOLING OPTION
Default resistance (31.4 KOhms) + 1.5 KOhms = 32.9 KOhms
Operating on condition that R-SENSOR OFF point goes down 1ºC.
36
