10
PART DETAILS
Drain Pan Assembly
Condenser Fan Motor Assembly
3-3. Electrical Box
Drain Wicking Bar
Drain Pan
Condenser
Fan Motor
Bracket
Condenser Fan
Motor Blade
Power Relay (Comp. Relay)
Power Bushing
Drain Wicking Pads
FD,SD-650R,1250R¿ 12– ` (¿) 02.8.21 4:48 PM ˘`10
