5. ELECTRONIC CONTROLLER INSTRUCTION
5-1. FREEZER CONTROLLER
5-1-1. HOW TO USE THE PANEL
9
TEMPERATURE T.F.
8
7
6
5
4
3
2
1
FAN DOOR
TURBO FREEZE
TEMPERATURE
˚F
- Bar LED
- It indicates setting
temperature level
- 88 LED
- It indicates inside
temperature, except
defrost function
- Temperature can be controlled by the user.
- Not controllable during ‘Turbo Freeze’ mode.
- Factory setting is at level ‘5’. Settings can be
changed by pressing up/down button.
The compressor operates continuously for 120
minutes during ‘Turbo Freeze’ mode.
‘Turbo Freeze’ Mode can be cancelled by pressing
“Turbo Freeze button” during ‘Turbo Freeze’ Mode.
