REPLACEMENT OF MAIN COMPONENTS
7-4. CONDENSING UNIT
- Condensing units : Compressor, Condenser Fan Motor, Condenser Coil, Condenser Dryer....
- Others : Compressor Power Cord (Relay harness), Main Power Cord, Electrical Box, ETC.
A. Disassemble Bottom Grille as described section 7-2. B.
B. Unscrew two screws as below.
C. Unplug the compressor’s power plug.
