PART LIST (FR-360, FR-390)
NO PART CODE
PART NAME PART DESCRIPTION QUANTITY REMARK
1
ASSY CAB URT FR-360(R-141b) - HCFC 1
ASSY CAB URT FR-360(R-11) - CFC 1
ASSY CAB URT FR-390(R-141b) - HCFC 1
ASSY CAB URT FR-390(R-11) - CFC 1
1-1 3017001700
EVAPORATOR SAS 1
1-2 3018111801
SWITCH BI-MATAL AS ST-3A AC250V 5A 1
1-3 3017200602
FUSE TEMP AS 1
1-4 4017Z90590
FIXTURE FUSE TEMP 1
1-5
HEATER D AS 1
1-5-1 4017Z73570
COVER DEFROST HTR *T AL T0.4 1
1-5-2
HEATER D AS 1
1-5-3 4017Z73580
COVER DEFROST HTR *U AL T0.4 1
2
MACHINE ROOM
2-1 3010317530
BASE COMP AS SBHG T1.0 1
2-2 3010100201
ABSORBER COMP NR H=40 4
2-3 3012610000
BAND RELAY SK-5 T0.7 1
2-4
SWITCH RELAY AS 1
2-5 3016002500
SPECIAL WASHER SWRH 4
2-6
COMPRESSOR 1
2-7
DRYER AS 1
2-8 3013201710
HOSE DRAIN B PP 1
2-9 7112401211
SCREW TAPPING T1 TRS 4 X 12 2
2-10 3014436300
PIPE WICON AS 1
2-11 3011200500
CLAMP FAN SUS304 1
2-12 3011802200
FAN ABS 3.17 1
2-13 3012006000
FIXTURE C MOTOR AS 1
2-14
MOTOR C 1
2-15 3011117400
CASE VAPORI PP 1
3
MOTOR F AS 1
3-1 4017Z32244
COVER FAN MOTOR(B) HIPS 1
3-2 4017Z08430
ABSORBER MOTOR EPR-B3 2
3-3
MOTOR AS 1
3-4 4017Z32233
COVER FAN MOTOR(C) HIPS 1
3-5 4019H32230
COVER FAN MOTOR(A) HIPS 1
3-6 4019H10310
FAN ABS 3.17 1
3-7 4019H10600
RING FIX FAN STS 27 1
