15
2. Parts list
NO PART CODE PART NAME DESCRIPTION QUANTITY REMARK
1 ASSY URT CAB 1
2 3012500100 GUIDE DRN AL200P T0.3 1
3 HIR GLASS TUBE AS 1 REFER TO # 9
4 4017Z73570 COVER DEFR HTR*T AL 1
5 4017Z73580
4010G19010
COVER DEFR HTR*U
FIXTURE DEFR HTR
AL 1
2
7
6
LAMP AS 3 REFER TO # 9
8 PFFRFRH130 ASSY COOLER COOLER LINE 1
9 400EL21213 FUSE TEMP AS 77ûCoff 1
10 4017Z90590 FIXTURE FUSE TEMP PP 1
11 3018111100 SWITCH BIMTL AS 9ûC off 1
12 3018100010 SWITCH DR DSD-5 1
13 3010300800 BASE COMP SBHG1 T1.4 1
14 3014500105 PLATE AXCON AS PIPE CON L5876 1
15 3010602104 BRACKET ADJ-FT *L AS 1
16 3010602604 BRACKET ADJ-FT *R AS 1
17 3010100201 ABSORBER COMP NR H=40 4
18 COMPRESSOR 1 REFER TO # 8
19 DRYER AS 1 REFER TO # 9
20 4019H09030 SPECIAL WASHER SWRH 4
21 SWITCH P RELAY AS 1 REFER TO # 8
22 3016100100 SPECIAL SCREW M6X20 4
23 3012900630 HINGE *M AS ZN DC-2 1
24 3016000220 SPECIAL SCREW M6X16 SWCH22A 2
25 MOTOR SHADED AS 1 REFER TO # 9
26 4017Z86412 FAN MOTOR COVR (A) HIPS 1
27 4017Z32244 COVER MOTR B HIPS 1
28 4017Z32233 COVER MOTR C HIPS 1
29 4017Z42312 FAN ABS 1
30 TIMER 1 REFER TO # 9
31 401NA29101 HOLDER DEFR TIMER PP 1
32 3012000303 FIXTURE SHELF HIPS 2
33 3011416000 COVER M/F DUCT AS 1
34 3013300500 INSULATOR DAMP B F-PS 1
35 4010G26401 R DAMPER AS HF 380 1
36 4017G31152 KNOB DAMP ABS 1
37 3015500703 WINDOW R GPPS 1
38 ASSY URT *T DOOR 1 REFER TO # 11
39 3019005900 POCKET F *T GP 2
40 3012300002 GASKET F DR PVC-S 1
To Next Page
