Door removal/Replacement
If the refrigerator can not pass
through a door during installation,
follow these steps.
(This guide refers to several models. The real features
are model dependent.)
Removing Refrigerator Door
Remove front bottom cover first, if it is attached.
↜
1
Unscrew top hinge cover with a screwdriver. Insert
a thin screwdriver into the side groove of the cover
to remove.
2
Turn top hinge fastener counterclockwise
3~4 times. Disconnect harness wires (model
dependent).
3
Lift up the front of hinge to remove. (After the hinge
is removed the door can fall down forward. Be
careful !)
4
Lift the door straight up to remove.
Removing Freezer Door
1
Pull out bending tube guide and the left water tube.
(Dispenser Models Only)
2
Unscrew top hinge cover with a screw driver.
3
Turn top hinge fastener counterclockwise 3~4
times. Disconnect the harness wires.
4
Lift up the front of hinge to remove. (After the hinge
is removed the door can fall down forward. Be
careful!)
5
Be careful not to damage the water line when
removing the door.
