1
Unscrew top hinge cover with a screw
driver.
Insert a thin screw driver into the side
groove of the cover to remove.
2
Turn top hinge fastener counterclockwise
3~4 times.
Disconnect harness wires.
3
Lift up the front of hinge to remove. (After
the hinge is removed the door can fall
down forward. Be careful !)
4
Lift the door straight up to remove.
Removing Refrigerator Door
To Next Page
