1
Insert the bottom hole of freezer door
straight to the bottom hinge pin.
2
Let the top of door close to the cabinet and
insert the top hinge pin to the top hole of
freezer door.
( Insert the back of hinge to the groove of
protrusion first, then front to the top hole of
door.)
3
Turn the hinge fastener tightly to the end.
Connect harness wirings and screw ground
wire.
4
Click and screw the top hinge cover.
