Daewoo KOC-960P0A - Page 28

31
11. To remove tray motor. (Refer to Fig. 11)
(1) Cut the tray motor cover parts from the base plate (Refer to
Fig. 11, 12).
(2) Remove the tray motor cover.
(3) Remove two screws ¤Łwhich secure the tray motor ¤ .
(4) Remove the tray motor.
Fig. 12
Fig. 11
(Front)
Slit
Nipper
File
(Bottom)
¤
¤Ł
