49
REF No. PART CODE PART NAME DESCRIPTION Q’TY REMARK
A00 3511703610 DOOR ASS’Y KOC-960PØS 1
A02 3515200800 STOPPER HINGE * T SCP-1 2.5T 1
B00
PKCPSWQJ00 KOC-960PBS ROTISSERI
PKCPSWQJ00
CONTROL PANEL AS
KOC-960PØS 1
B04 441P655031 LEVER DOOR OPEN ACETAL
F01
3516104600
CAVITY WELD ASS’Y
KOC-961C0S 1
3516104610 KOC-961CBS ROTISSERI
F02 7S627W50X1 NUT HEX NUT FLANGE M5X0.8P MFZN 3
F03 7112400811 SCREW TAPPING T1 TRS 4X8 MFZN 1
F04 3512505500 GUIDE AIR OUTLET SAID-80 0.5T 1
F05 7S627W50X1 NUT HEX NUT FLANGE M5X0.8P MFZN 2
F06 7112400811 SCREW TAPPING T1 TRS 4X8 MFZN 2
F07 3511401900 COVER INSULATOR * T ASS’Y KOC-961C0S 1
F08 3517202601 TRAY RACK ASS’Y KOC-961C0S 250X27 1
F09 3517202611 TRAY RACK ASS’Y KOC-961C0S 250X117 1
F10 3517204900 TRAY METAL AS SPP TO.8 1
F11 3512507400 ROLLER GUIDE ASS’Y KOC-961C0S 1
F12 3517400110 COUPLER TEFLON 1
F13 3512800710 HEATER 1R07835 120V 1350W 1
F14 3512506700 GUIDE ROTARY TEFLON 1 ROTISSERI
F15 7112400811 SCREW TAPPING T1 TRS 4X8 MFZN 1 ROTISSERI
F16 7650501611 BOLT HEX 6B-1 5X16 HS MFZN 2
F17 7112400808 SCREW TAPPING T1 TRS 4X8 SUS 2
F18 3511401600 COVER WAVE GUIDE MICA 0.35T 1
F19 7S627W50X1 NUT HEX NUT FLANGE M5X0.8P MFZN 2
F20 7650501611 BOLT HEX 6B-1 15X16 HS MFZN 2
F21 3510306600 BASE PLATE SBHG 0.8T 1
F22 4413A12030 FOOT P.P 4
F23 4413A12010 FIXTURE FOOT P.P 4
F24 7112400811 SCREW TAPPING T1 TRS 4X8 MFZN 7
F25 7112400811 SCREW TAPPING T1 TRS 4X8 MFZN 2
F26 7S327W50B1 SCREW TAPPING T2 FLANGE 5X12 MFZN 4
F27 441AZ80050 TRANS POWER KOC-881P 1
F28 7S422X4081 SCREW SPECIAL TT2 TRS 4X8 SE MFZN 1
F29 3513001700 HOLDER HV CAPACITOR SECC 0.8T 1
F30 4415T66300 CAPACITOR H.V 2100V AC 0.98uF 1
F31 7S422X4081 SCREW SPECIAL TT2 TRS 4X8 SE MFZN 1
F32 3518400100 DIODE HV HVR-1X-72B 1
F33
3518103820
H.V TRANS
HMOT-N10A0 1 S
3518103830 DY-N10A0-96T
F34 3513700300 LEVER DAMPER MSWR 1
F35 3519000100 SOLENOID DC DC 12V DET-SL-007 1
F36 3512508000 GUIDE AIR WELD ASS’Y KOC-961C0S 1
F37 4414D25130 HOLDER FUSE BUSSMANN S-8202-01 1
F38 7121300811 SCREW TAPPING T2S PAN 3X8 MFZN 1
F39 4417B67600 FUSE UL/CSA NM15A 250V MF61 1
F40 7121300811 SCREW TAPPING T2S PAN 3X8 MFZN 1
F41 3515400200 VALVE DAMPER SBHG-1 TO.5 1
* S : Subsititutive
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
