1) Transistor (NON Type) 2) Transistor (PNP Type)
3) Diode and zener diode
Emitter Base
Q1, Q2, Q4~Q11
Collector
DIODE Cathode (K) ANODE (A) D1-12
ZENER DIODE Cathode (K) ANODE (A) ZD1-4
Emitter Collector
Q3
Base
Emitter Collector Base
