60
P.C.B. LOCATION NO.
REF NO. PART-NAME DESCRIPTION PART-CODE Q’TY REMARK
PCB PCB MAIN M205 3514304650 1
RESISTOR 4.7KΩ 1/4W, 5% RD-4K472J- 10
R7 RESISTOR 4.7KΩ 1/4W, 5% RD-4K472J- 1 ROTISSERIE
R30 RESISTOR 4.7KΩ 1/4W, 5% RD-4K472J- 1 SLOW ACTING
R2 RESISTOR 4.7KΩ 1/4W, 5% RD-4K331J- 1
R5 RESISTOR 330Ω 1/4W, 5% RD-4K331J- 1
R4 RESISTOR 1MΩ 1/4W, 5% RD84K105J- 3
R19,R20,R24,R27,R33 RESISTOR 1KΩ 1/4W, 5% RD-4K102J- 3
R3 RESISTOR 1KΩ 1/4W, 5% RD-4K102J- 1
R12 RESISTOR 10KΩ 1/4W, 5% RD-4K103J- 1
R13,R15,R35 RESISTOR 100KΩ 1/4W, 5% RD-4K104J- 3
R40,R42,R43,R44 RESISTOR 27Ω 1/4W, 5% RD-4K270J- 4
R32 RESISTOR 27Ω 1/4W, 5% RD-4K270J- 1 ROTISSERIE
R39 RESISTOR 27Ω 1/4W, 5% RD-4K270J- 1 SLOW ACTING
R34 RESISTOR 5.1KΩ 1/4W, 5% RD-4K512J- 1
R41 RESISTOR 51Ω 1/4W, 5% RD-4K510J- 1
R25,R26,R37 RESISTOR 100Ω 1/4W, 5% RD-4K101J- 1
R38 RESISTOR FUSIBLE 1Ω 1/2W, 5% RF-2Z109J- 1
R21, R22 RESISTOR 200Ω 1/4W, 5% RD-4K201J- 2
R14 RESISTOR METAL FILM 13KΩ 1/4W, 1% RN-4K1302F 1
R23 RESISTOR METAL FILM 150KΩ 1/4W, 1% RN-4K1503F 1
R11 RESISTOR M-OXIDE 2Ω 1W, 5% RS01Y020J- 1
D1,D6,D10,D11,D12,D13 DIODE SWITCHING 1N4148 DKN4148--- 6
D8 DIODE SWITCHING 1N4148 DKN4148--- 1 ROTISSERIE
D9 DIODE SWITCHING 1N4148 DKN4148--- 1 SLOW ACTING
D3,D4,D5,D7 DIODE RECTIFYING 1N4002A DKN4002A-- 4
D2 DIODE RECTIFYING 1N4002A DKN4002A-- 1
ZD2 DIODE ZENER MTZ224VD, 1/2W DKTZ24D--- 1
ZD1 DIODE ZENER MTZ3.0VB, 1/2W DZTZ3R0B-- 1
ZD4 DIODE ZENER MTZ39VB, 1/2W DZTZ3R9B-- 1
ZD3 DIODE ZENER U5.6VB, 1/2W DZTZ5R6B-- 1
Q2,Q6,Q8,Q9,Q10,Q11 TRANSISTOR KTC3198GR TZTC3198GR 6
R1,R8,R10,R16,R17,R18
R28,R29,R31,R36
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
