REF NO. PART NAME PART CODE DESCRIPTION Q’TY REMARKS
A00 DOOR ASS’Y
EXPLODED AND PART LIST
1
B00 C/PANEL ASS’Y 1
F01 COVER WAVE GUIDE 3511403500 MICA T0.5 1
F02 BUTTON LOCKING 4078502031 PP 2
F03 INSULATOR HEATER AS 3513301400 KOG-36150S 1
F04 COUPLER 3517400600 PPS 1
F05 GUIDE ROLLER AS 3512510600 KOR-61150S 1
F06 TRAY 3517203600 GLASS 1
F07 TRAY RACK AS 3517204410 KOG-361Q0S 99MM 1
F08 CABINET 3510801300 PCM T0.6 1
F09 SCREW TAPPING 7S312X40A1 T1 TRS 4X10 SE MFZN 3
F10 SCREW SPECIAL 3516003700 TT3 FLG HEX 4X8 MFZN 2
F11 NUT HEX 7S627W50X1 FLG NUT M5X0.8P MFZN 2
F12 CAVITY AS 3516104810 KOG-36150S 1
F13 SCREW TAPPING 7122401211 T2S TRS 4X12 MFZN 1
F14 SCREW TAPPING 7121300611 T2S PAN 3X6 MFZN 1
F15 THERMOSTAT 3513902200 OFF:130 ON:115 1
F16 SCREW TAPPING 7112401011 T1 TRS 4X10 MFZN 3
F17 NUT HEX 7S627W50X1 FLG NUT M5X0.8P MFZN 2
F18 CLAMP POWER CORD 4413A90012 NYLON 66 1
F19 CORD POWER AS 35113AAQ95 3X0.75 60X60 120-RTML 1
F20 MAGNETRON 3518002200 2M 218H(MF) I 1
F21 SCREW SPECIAL 3516002700 T2S FLG HEX 4X13 SE MFZN 3
F22 SCREW TAPPING 7S312X40A1 T1 TRS 4X10 SE MFZN 2
F23 SCREW MATCHINE 7601400811 PAN 4X8 PW MFZN 2
F24 COVER *B 3511402500 SBHG T0.8 1
F25 MOTOR SHADED POLE 3963512100 MW10CA-R01 1
F26 FAN 3511800300 PP+30% GLASS 1
F27 SCREW TAPTITE 7272400811 TT3 TRS 4X8 PW MFZN 1
F28 HOLDER HV CAPACITOR 3513001900 SECC T0.8 1
F29 CAPACITOR H.V 441U667020 2100VAC 0.95uF 1
F30 DIODE H.V. 4416V24000 HVR-1X-32B 1
F31 TRANS H.V. 3518106210 JY-N80S0-61T 1
F32 SCREW SPECIAL 3516003700 TT3 TRS 4X8 MFZN 4
F33 SCREW TAPPING 7112401011 T1 TRS 4X10 MFZN 5
F34 BASE 3510308700 SBHG T0.8 1
F35 FOOT 3512100900 PP DASF-130 2
F36 SCREW TAPTITE 7272400811 TT3 TRS 4X8 MFZN 2
F37 STOPPER HINGE *U 3515201101 SCP-1 T2.5 1
F38 SCREW TAPPING 7122401211 T2S TRS 4X12 MFZN 2
F39 SW MICRO 4415A17352 VP-533A-OF 1
F40 SW MICRO 4415A66910 VP-531A-OF 1
F41 SW MICRO 4415A17352 VP-533A-OF 1
F42 LEVER LOCK 3513701300 POM 1
F43 LOCK 3513805700 POM 1
F44 LAMP 3513601600 BL 240V 25W T25 1
F45 NOISE FILTER 3518603700 DWLF-M 1
F46 SCREW TAPPING 7121400611 T2S TRS 4X6 MFZN 2
F47 MOTOR SYNCRO 3966310100 GM-16-24FD12 1
F48 FUSE H.V 3518700900 HV-41A 5KV 0.55A #250 1
F49 SLOW ACTING RELAY 3518570400 DWSR-1 1 for Germany
F50 SCREW TAPPING 7122401211 T2S TRS 4X12 MFZN 1
PARTS LIST
