EXPLODED VIEW AND PARTS LIST
1) KOR-630A0A
REF NO PART CODE PART NAME DESCRIPTION Q'TY
A00 3511710320 DOOR AS KOR-63050S 1
B00 PKCPSWZF00 CONTROL-PANEL AS KOR-630A0A 1
F01 3510801310 CABINET PCM T0.36 GE 1
F02 3516004100 SPECIAL SCREW T1 TRS LR4 POLE 4*10 MFZN 3
F03 3516109000 CAVITY WELD AS KOR-63150S 1
3516109600 CAVITY JOINT AS KOR-63150S 1
F04 7112401011 SCREW TAPPING T1 TRS 4*10 MFZN 1
F05 7122401211 SCREW TAPPING T2S TRS 4*12 MFZN 1
F06 7122401211 SCREW TAPPING T2S TRS 4*12 MFZN 1
F07 7112401011 SCREW TAPPING T1 TRS 4*10 MFZN 1
F08 35113NAN0H CORD POWER AS 3X18AWG 60X60 120-RTML 1
F09 4413A90012 CLAMP POWER CORD NYLON66 1
F10 7122401211 SCREW TAPPING T2S TRS 4*12 MFZN 1
F11 7121403011 SCREW TAPPING T2S PAN 4X30 MFZN 2
F12 3963821600 MOTOR SHADED POLE 120V 21W OEM-10DWX1-A07 1
F13 3512517000 GUIDE WIND PP 1
F14 3511800300 FAN PP+30%GLASS 1
F15 3518002200 MAGNETRON 2M218H(MF) I 1
F16 3516004000 SPECIAL SCREW T2 BOLT FLANGE 5X12 DACRO 1
F17 7272400811 SCREW TAPTITE TT3 TRS 4X8 MFZN 1
F18 3513003200 HOLDER HV CAPACITOR SECC T0.6 1
F19 3518301600 CAPACITOR HV 2100VAC 0.79uF #187 1
F20 3518400400 DIODE HV HVR-1X-3AB 12KV #187 1
F21 3518114400 TRANS HV JMOT-N80A0-63T 1
F22 3516003700 SPECIAL SCREW TT3 HEX 4X8 FLG MFZN 4
F23 3510311700 BASE SBHG T0.8 1
F24 7112401011 SCREW TAPPING T1 TRS 4*10 MFZN 5
F25 3512100900 FOOT PP DASF-130 2
F26 7272400811 SCREW TAPTITE TT3 TRS 4X8 MFZN 1
F27 3515201101 STOPPER HINGE *U SCP-1 T2.5 1
F28 - FUSE 120/250V 15A 1
F29 - HOLDER FUSE NYLON66 1
F30 4415A17352 SW MICRO VP-533A-OF SPNO #187 200G 1
F31 4415A66600 SW MICRO VP-532A-OF/SZM-V16-FA-62 1
F32 4415A17352 SW MICRO VP-533A-OF SPNO #187 200G 1
F33 3513702600 LEVER LOCK POM 1
F35 3513811700 LOCK POM 1
F36 3513601500 LAMP BL 125V 25W T25 C5A H187 1
F37 7121400611 SCREW TAPPING T2S PAN 4X6 MFZN 1
F38 3966820200 MOTOR SYNCRO 120V 2W GM-16-12F17 1
F39 3518905300 THERMOSTAT OFF:75 ON:65 H #187 NB 1
F40 3513003400 HOLDER THERMOSTAT PBT 1
F41 3516003700 SPECIAL SCREW TT3 HEX 4X8 FLG MFZN 1
F42 3511406200 COVER WAVE GUIDE HEATPROOF PP 1
F43 3517400620 COUPLER XAREC 1
F44 3514700710 ROLLER TEFLON 3
F45 3512517300 GUIDE ROLLER PP 5113MF6 A353B 1
F46 3517203600 TRAY GLASS 1
ā Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
