32
NO NAME SYMBOL SPECIFICATION PART CODE Q’TY
1 BUZZER BZ1 BM-20K 3515600100 1
2C ARRAY CA1 7P(6) 1000PF M 50V CN6XB-102M 1
3 CAPACITOR ELEC EC1 50V RS 10UF CEXE1H100A 1
4 CAPACITOR ELEC EC2 25V RSS 1000MF CEXF1E102V 1
5 CONNECTOR WAFER CN1 YW396-02V 3519150520 1
6 CONNECTOR WAFER CN2 HLEM15S-1 4CW215SBD0 1
7 CONNECTOR WAFER CN3 YW396-05AV 3519150510 1
8 DIODE RECTIFY D1~6,D8,D9,D11,D12,D15 1N4148 DZN4148--- 11
9 DIODE RECTIFY D13.14 KN4004A DZN4004A-- 2
10 DIODE ZENER ZD1 UZ- 3.3BSB 1/2W DZUZ3R3BSB 1
11 DIODE ZENER ZD2 UZ- 5.1BSB 1/2W DZUZ5R1BSB 1
12 IC MICOM IC1 HMS81C1716B-HN057 150SR8A3K- 1
13 LED DISPLAY DP1 T0F-4461BH-B10 DT0F4461BH 1
14 PCB MAIN M336 86X163.5 3514331620 1
15 R ARRAY RA1 8P(7) 1/8 100K OHM J RA-88X104J 1
16 R ARRAY RA2 7P(6) 1/8 100K OHM J RA-87X104J 1
17 RESISTOR R11 1/6W 200 5% RD-AZ201J- 1
18 RESISTOR R1~7 1/6W 330 5% RD-AZ331J- 7
19 RESISTOR R12,R23,R21,18 1/6W 1K 5% RD-AZ102J- 4
20 RESISTOR R8,R16 1/6W 4.7K 5% RD-AZ472J- 2
21 RESISTOR R10,R13,R25,R26 1/6W 10K 5% RD-AZ103J- 4
22 RESISTOR R9 1/6W 47K 5% RD-AZ473J- 1
23 RESISTOR R14 1/6W 1M 5% RD-AZ105J- 1
24 RESISTOR R19 1/4W 51 5% RD-4Z510J- 1
25 RESONATOR CERA CR1 CRT 4.00MS 5P4R00MTS- 1
26 IC REGULATOR VL1 MC7805C 1CPMC7805C 1
27 TRANSISTOR Q1~5 KRA106M TZRA106M-- 5
28 TRANSISTOR Q14,Q10,Q9 KRC106M TZRC106M-- 3
29 TRANSISTOR Q6,Q7 KTA-1266Y TZTA1266Y- 2
30 TRANSISTOR Q13 KTC-3198GR TZTC3198GR 1
31 CAPACITOR CERA C4 102 50V Z AXIAL CCZB1H102K 1
32 CAPACITOR CERA C1~3,C5,C6 104 50V Z AXIAL CCZF1H104Z 5
33 TRANS POWER LVT1 DMR-631FS 5EPV035303 1
34 WIRE COPPER J1,2,10,J12~14 1/0.52 TIN COATING 7.5MM 85801052GY 6
35 WIRE COPPER J3~6,J7~9,11,15 1/0.52 TIN COATING 10MM 85801052GY 9
36 WIRE COPPER SJ3,6 1/0.52 TIN COATING 85801052GY 2
37 SW RELAY RY1 G5G-1A DT DC12V 5SC0101123 1
38 SW RELAY RY2 CS11-12SH 1C 1P 5SC0101128 1
NO NAME SYMBOL SPECIFICATION PART CODE Q’TY
1 CONN WAFER CN101 HLEM15R-1 4CW215RBD0 1
2 PCB SUB M337 77X115.5 3514331720 1
3 SW ROTARY EN101 EC12E24204A8 5S10302005 1
4 SW TACT SW101~SW110 KPT-1115AM 5S50101Z93 10
5 WIRE COPPER J101,J102 1/0.52 TIN COATING 10MM 85801052GY 2
6 WIRE FLAT WF1 1.25X15X90XC WSJ-159007 1
3. PCB LOCATION NO.
*MAIN PCB ASS'Y
*SUB PCB ASS'Y
