10
1. To remove cabinet
1) Remove three screws on cabinet back.
2) Pull the cabinet backward.
2. To remove door assembly
1) Remove two screw which secure the stopper hinge top.
2) Remove the door assembly from top plate of cavity.
3) Reverse the above for reassembly.
NOTE : After replacing the door assembly, perform a check of correct alignment with the hinge and cavity front plate.
