Daewoo KOR-61A5 Service Manual

9
WIRING DIAGRAM
HIGH VOLTAGE TRANSFORMER
H.V.T THERMAL CUT-OUT
H.V.
CAPACITOR
H.V. DIODE
CL GM FMTM
POWER SUPPLY : SINGLE PHASE ~ ONLY
RD
RD
WH
FILTER ASS'Y
FUSE
L
NN
GN
L
BR(BK) BL(WH) GE(GN)
PRIMARY INTERLOCK SWITCH(UPPER)
TIMER ASSY
TIMER SWITCH
V.P.C
NO
COM
INTERLOCK MONITOR SWITCH
NC
BK
WH
BL
SECONDARY INTERLOCK SWITCH
WH
GY
GY
GY
GY
GY
GY
OR
MAGNETRON
1 3
2
M
RD OR
NOTE RD : RED NOTE WH : WHITE NOTE BK : BLACK NOTE GN : GREEN NOTE BR : BROWNNOTE
OR : ORANGE BL : BLUE GY : GRAY GE : GREEN/YELLOW
CL : CAVITY LAMP FM : FAN(BLOWER) MOTOR GM : GEARED MOTOR TM : TIMER MOTOR V.P.C : VARIABLE POWER CONTROLLER
[CONDITION] DOOR : CLOSED TIMER : ON V.P.C. : HIGH
NOTE :
THERMOSTAT (KOR-6185ON)
*
