Daewoo KOR-6NDB - PCB Location No. (KOR-6 NDB3 A)

29
NO NAME SYMBOL SPECIFICATION PART CODE Q'TY REMARK
1 BUZZER BZ1 BM-20K (BUJEON) 3515600100 1
2 C ARRAY CA1 7P(6) 1000PF M 50V 2.54MM CN6XB-102M 1
3 CONN WAFER CN1 YW396-02V(YEONHO) 3519150520 1
4 CONN FILM CN2 FCZ 254-11(YEON HO) 441M367160 1
5 CONN WAFER CN3 YW396-05AV(YEONHO) 3519150510 1
6 LED DISPLAY DP1 LTC-4651HG(631) DDDG631H02 1
7 C ELECTRO EC2 25V RSS 1000MF (13X20) TP CEXF1E102V 1
8 IC MICOM IC1 HMS81C1708B-HN017-1 150SR6N6Q- 1
9 TRANS POWER LVT1 DMR-631P 5EPU035302 1
10 SW RELAY RY1 G5G-1A 1C 1P DC12V 5SC0101121 1
11 SW RELAY RY2 CS11-12SH 1C 1P 5SC0101128 1
12 WIRE COPPER SJ1~2,4~5 1/0.52 TIN COATING 85801052GY 4
13 IC REGULATOR VL1 MC7805C(S/S) 1CPMC7805C 1
14 RESONATOR CERA CR1 CRT 4.00MS 5P4R00MTS- 1
15 C ELECTRO EC1 50V RS 10MF (5X11) TP CEXE1H100A 1
16 TR Q01~5 KRA106M(AUTO) TZRA106M-- 5
17 TR Q06 KTA1266Y- (AUTO)(1015Y) TZTA1266Y- 1
18 TR Q09~11 KRC106M(AUTO) TZRC106M-- 3
19 R ARRAY RA1 8P(7) 1/8 100K OHM J RA-88X104J 1
20 R ARRAY RA2 7P(6) 1/8 100K OHM J RA-87X104J 1
21 PCB MAIN BOARD M158-1 3514315411 1
22 C CERA C01~4,6~7 HIKF 50V 0.1MF Z AXIAL CCZF1H104Z 6
23 C CERA C05 50V B 1000PF K (AXIAL) CCZB1H102K 1
24 DIODE D01~5,8~12 1N4148 AUTO 52MM DZN4148--- 10
25 DIODE D13~14 KN4004A AUTO 52MM DZN4004A-- 2
26 WIRE COPPER J01~10,13~14 1/0.52 TIN COATING 85801052GY 12 7.5mm
27 WIRE COPPER J11~12 1/0.52 TIN COATING 85801052GY 2 10.0mm
28 R CARBON FILM R01,10,12,17,18,22 1/6 1K OHM J RD-AZ102J- 6
29 R CARBON FILM R02~8 1/6 330 OHM J RD-AZ331J- 7
30 R CARBON FILM R09 1/6 100K OHM J RD-AZ104J- 1
31 R CARBON FILM R11 1/6 200 OHM J RD-AZ201J- 1
32 R CARBON FILM R13,19~20 1/6 10K OHM J RD-AZ103J- 3
33 R CARBON FILM R14 1/6 1M OHM J RD-AZ105J- 1
34 R CARBON FILM R21 1/4 51 OHM J RD-4Z510J- 1
35 DIODE ZENER ZD1 UZ-3.3BSB(3.32-3.53V) DZUZ3R3BSB 1
36 DIODE ZENER ZD2 UZ-5.1BSB(4.97-5.18V) DZUZ5R1BSB 1
3. PCB LOCATION NO. (KOR-6NDB3A)
