Daewoo Lanos 2002 - Page 143

SERVICE AND MAINTENANCE 7–29
SIDE TURN SIGNAL LAMP*
1. Remove the side turn signal lamp assem-
bly with pulling it rearward.
2. Rotate the bulb holder counterclockwise
and remove it from the lamp housing.
3. Remove the bulb by pulling straight out
of the holder.
4. Replace the bulb with a new one.
5. Install in the reverse order of removal.
TAIL, BRAKE, REVERSE AND
REAR TURN SIGNAL LAMP
(Notchback Model)
1. Open the trunk lid and remove the pro-
tective cover.
2. Rotate the bulb holder counterclockwise
and remove the bulb holder from the
lamp housing.
3. Depress the bulb and rotate it anticlock-
wise to remove it from the bulb holder.
4. Replace the bulb with a new one.
5. Install in the reverse order of removal.
6. Bulb sequence.
Tail & brake lamp
Turn signal lamp
Reverse lamp
Upper
Middle
Lower
