7–30 SERVICE AND MAINTENANCE
(Hatchback Model)
To replace tail, brake and rear turn signal
lamp bulbs;
1. Open the tailgate.
2. Remove two fixing screws.
3. Rotate the bulb holder counterclockwise
and remove the bulb holder from the
lamp housing.
4. Depress the bulb and rotate it counter-
clockwise to remove it from the bulb
holder.
5. Replace the bulb with a new one.
6. Install in the reverse order of removal.
7. Bulb sequence.
Turn signal lamp
Tail & brake lamp
Outer
Inner
To replace reverse lamp bulbs;
1. Open the tailgate.
2. Remove the protective cover.
3. Remove the bulb holder from the lamp
housing.
4. Depress the bulb and rotate it counter-
clockwise to remove it from the bulb
holder.
5. Replace the bulb with a new one.
