4–2 VENTILATION, HEATING AND AIR CONDITIONING*
CONTROL PANEL
1. Temperature control switch
2. Fan control switch
3. Air distribution switch
4. Air intake lever
5. Air conditioning switch*
6. Rear window demister switch
VENTILATION AND HEATING
Air mixture system: by mixing cold and hot
air the temperature can be regulated with-
out delay and thereby held practically con-
stant at all speeds.
The rate of air flow is determined by the fan.
The fan should therefore be switched on if
required even when driving.
REAR HEATING DUCT*
Cold or heated air is routed to the rear foot
area via ducts underneath the front seats.
123
4
5
6
