VENTILATION, HEATING AND AIR CONDITIONING* 4–3
SIDE VENTILATION VENTS
Air can be directed into the vehicle via both
side ventilation vents.
FRONT DOOR WINDOW
DEFROSTER VENTS
Cooled and warm air will be directed onto
the windshield and onto the side windows
(mainly in the area of the outside mirror).
TEMPERATURE CONTROL
SWITCH
The temperature control switch is used to
control the temperature of the air that comes
out of the air vents.
Blue colored position : cold
Red colored position : hot
1. Front door window defroster vents 3. Center ventilation vents
2. Side ventilation vents
12 213
CENTER VENTILATION VENTS
Air can be directed into the vehicle via both
center vents.
The air flow can be directed as desired by
tilting and swivelling the fins.
