PERFORMANCE SPECIFICATIONS
MODEL NO : MC-100UBM
Frequency Modulation ( FM) Section
Test Item Unit Normal Limit #1 #2
F01 Tuning Range TP:87.5MHz LOW MHz 87.5 +/-0.1
TP:108MHz High MHz 108 +/-0.1
F02 Sensitivity TP:90.1MHz 90.1MHz dB/uv 20
≦28
at 30dB S/N TP:98.1MHz 98.1MHz dB/uv 20
≦28
(Mono) TP:106.1MHz 106.1MHz dB/uv 20
≦28
F03 3 dB Limit Sens TP:98.1MHz 98.1MHz dB 18
≦27
F04 Stereo Threshold TP:98.1MHz 98.1MHz dB 26
≦32
F05 Overload TP:98.1MHz 98.1MHz dB > =110
F06 Audio Response -6dB
TP:98.1MHz 98.1MHz Hz/KHz 60/4K5
150/3K5
F07 Separation (1K) TP:98.1MHz 98.1MHz dB 30
≧20
F08
Total Harmonic Distortion (60dB) Mono Ref.
22.5KHz % 1
≦3
Max Power 75KHz % 10
≦20
F09 Signal to Noise Ratio (Input 60dB) 98.1MHz dB 50
≧45
TP:98.1MHz STEREO dB 45
≧40
F10 Auto Search Threshold 98.1MHz dB 27
≦35
TP:98.1MHz
F11 Mod. Hum (AC) TP:98.1MHz 98.1MHz dB 45
≧40
F12 Min. Volume Hum & Noise mV 0.7
≦2
