23
NO PART NAME PART CODE SPECS. Q
¡¡flfl
TY NOTE
1 PIPE 3624402900 ABS 1
2 TERMINAL AS 3628705700 TERMINAL +WIRE 2
3 SPRING 3625101700 HSW3 1
4 BUTTON 3626601000 ABS 1
5 COVER 3621404600 ABS 1
6 SCREW TAPPING 7121300812 T2S PAN 3X8 MFZN BK 2
7 HOSE 3623202900 PVC-S/SWRS 1 1.3M
3623202920 1.5M
3623202930 1.8M
8 TAPE VINYL 2TU00019BK 19MM BLACK 0.5
9 COVER HOSE 4565A70040 PP 2
10 ADAPTER PIPE 3629100400 ABS 1
11 FRAME TERMINAL 3622200700 FRAME+TERMINAL AS 1
12 FRAME TERMINAL 3622200600 ABS 1
13 PACKING PIPE 3624002400 NBR 1
14 WAX SILICON 2291140301 TSC987 1CAN-200g 0.001
15 PIPE HOSE 3624403800 ABS 1
16 TERMINAL AS 3628704600 TERMINAL+WIRE+RECEP 2
17 COVER TERMINAL 3621409000 ABS 1
18 SCREW TAPPING 7121301011 T2S PAN 3X10 MFZN 1
19 PCB S/V AS 3624303900 200K 1
3624304800 500K
20 SCREW TAPPING 7121300800 T2S PAN 3X8 2
21 PLATE 3624500200 ABS 1
22 KNOB 3623400100 PC 1
23 COVER PIPE 3621409700 ABS 2
24 SCREW TAPPING 7121301211 T2S PAN 3X12 MFZN 1
