24
NO PART NAME PART CODE SPECS. Q
¡¡flfl
TY NOTE
1 COVER 3621401000 ABS 1
2 BUTTON 3626600200 POM 1
3 SPRING 3625100500 HSW3 1
4 PIPE 3624400500 ABS 1
4
3
2
1
PIPE ASSEMBLY ( I-1 )
