Daewoo RC-105 - Circuit Diagram; Diac Control; DC Control (230 V;50 Hz)

3
2. CIRCUIT DIAGRAM
BLUE
BLACK
WHITE
BLUE
BLACK
WHITE
MOTOR
THERMOSTAT
POWER CORD
AC 250V, 7A
AC 125V, 12A
POWER
C3
104K
C2
104K
FILTER COIL
120µH, 12A
TRIAC
SM16JZ47
R5
100 1W
R4
R3
P.C.B
C1
104K
DIAC
DB4
YELLOW
YELLOW
S/V
R1 R2
LR-03 LP-03
HARNESS ASS'Y
VOLTAGE R1 R2 R3 R4 SLIDE VOLUME THERMOSTAT
AC 110V/50, 60HZ 1KΩ 1/2W 1KΩ 1/2W 91KΩ 1/2W 91KΩ 1/2W 200KΩ 85˚C
AC 220V/50HZ 10KΩ 1/2W 10KΩ 1/2W 180KΩ 1/2W 240KΩ 1/2W 500KΩ 85˚C
AC 220V/60HZ 10KΩ 1/2W 10KΩ 1/2W 150KΩ 1/2W 160KΩ 1/2W 500KΩ 85˚C
-DIAC CONTROL
Thermostat
85˚C
MOTOR
VR1
471
C3
104K
250V
TRANS
(230/24)
BD
RS102
R5
1K OHM
1/4W
ZD
12V
C4
683K
250V
S/V R
200K OHM
or ON/OFF switch
R8
20K OHM
1/4W
R9
20K OHM
1/4W
R7
47K OHM
1/4W
TR1
C3202 R6
33K
1/4W
R3
1K OHM
1/4W
C1
104Z
C2
683K
250VAC
R2
100 OHM
1W
R1
220 OHM
1/4W
CHOKE COIL
130µH 13A
PHOTO COUPLER
TLP560J
G
T1
T2
TRIAC
-DC CONTROL (230V/50HZ)
