EXPLODED VIEW AND PARTS LIST
NO PART NAME PART CODE SPECS. Q'YT
1 BODY AS 3620409000 ASSY 1
2 ASSY MOTOR 3620013400 ASSY(RC-320S) 1
3 CORD REEL AS 3629507100 ASSY 1
4 NOZZLE CREVICE 3628100600 PP 1
5 COVER BODY AS 3621426200 ASSY 1
6 SCREW TAPPTITE 7171402011 TT2 PAN 4X20 MFZN 2
7 FILTER EXHAUST 3621906900 POLYESTER 1
8 COVER DUST AS 362145900 ASSY 1
9 COVER TOP(V) 3621424700 PP 1
10 KNOB 3623401700 ABS 1
11 HOSE AS 3623206200 ASSY 1
12 PIPE TELESCOPIC AS 3624412300 1
13 BRUSH PEDAL AS 3629307400 ASSY 1
