30
6-7. BRUSH ASSEMBLY
1) MODEL RC-320F, RC-320S(3629304900)
NO PART NAME PART CODE SPECS. Q'YT
1 BODY BRUSH 3620406400 PP 1
2 ROLLER-F BRUSH 3624703100 PP 2
3 SHAFT ROLLER 3624900900 PA 2
4 PICKER LITTER 3622700700 PA 2
5 PIPE BRUSH 3624408300 PP 1
6 NECK BRUSH 3628001600 PP 1
7 ROLLER-B BRUSH 3624703000 PP 2
8 COVER BRUSH 3621417200 PP 1
9 SCREW TAPPTITE 7171401411 TT2 PAN 4X14 MFZN 4
EXPLODED VIEW AND PARTS LIST
