Daewoo RC-320B - Pipe Assembly

32
6-8. PIPE ASSEMBLY
1) MODEL RC-320F (3624408500)
2) MODEL RC-320B (3624403510)
3) MODEL RC-320S (3624412300)
NO PART NAME PART CODE SPECS. Q'YT
1 PIPE EXTENSION 3624408500 PP 2
NO PART NAME PART CODE SPECS. Q'YT
1 PIPE STEEL 3624403510 SPC T=0.7(LD=32.6) 2
NO PART NAME PART CODE SPECS. Q'YT
1 PIPE STEEL AS 3624412300 SPC 1
EXPLODED VIEW AND PARTS LIST
