EXPLODED VIEW AND PARTS LIST
NO PART NAME PART CODE SPECS. Q'YT
1 BODY 3620408800 PP 1
2 ROLLER BACK 3624704900 PP 2
3 BRACKET ROLLER 3620601500 PP 1
4 ROLLER FRONT 3624703600 PP 1
5 SHAFT ROLLER 3624901000 SWRM 1
6 SCREW TAPPING 7128401212 T2S WAS 4X12 MFZN BK 1
7 HOLDER BRUSH 3623005500 PP 1
8 SCREW TAPPING 7121401412 T2S PAN 4X14 MFZN BK 1
9 HOLDER FILTER 3623005600 PP 1
10 FILTER IN 3621904200 POLYESTER 1
11 GASKET 3622301100 EPDM FOAM(715mm) 1
