2) Before separate BOBBIN(5), CORD PLUG(9) pull out from the pocket of BRACKET(1)
and push LEVER CR(2) for reducing the elasticity of REEL SPRING
3) Unscrew a SCREW (#20) and separate BOBBIN(5) from BRACKET(1)
and check the contackts between the Y TERMINALS(13,14) and RING TERMINALS(7,8)
4) Check LEVER SPRING(4)
5) If ROLLER BRAKE(3) is worn out and Unscrew a SCREW(5),
separate LEVER(2) from BRACKET(1) AND replace ROLLER BRAKE(3)
6) If REEL SPRING(17) is broken, unscrew 2 SCREW(19) and replace it.
7) Unscrew a SCREW(10) and HOLDER TERMINAL(6) from BOBBIN(5)
check the connections between POWER CORD(9) and RING TERMINAL(7,8)
8) When assembling, make ther reserved winding 5 revolutions of BOBBIN clockwise.
When disassembling, The REEL SPRING may spring out of the Cover
CAUTION
