No Part Name Part Code Descriptions Q'nty
1 BRACKET CR 3620603500 PP 1
2 LEVER CR 3623704200 ABS 1
3 STOPPER ASSY 3625200200 ASSY 1
4 SPRING LEVER CR 3625114100 HSW3(422.6G/845.2G) 1
5 SCREW TAPPING 7128401212 T2S WAS 4X12 MFZN BK 1
6 BOBBIN 3629200910
PP ( 복합 )
1
7 HOLDER TERMINAL 4565A36020 PP(5101SW,V-0) 1
8 TERMINAL 4565A36024 C2600P-1/2H T0.3 1
9 TERMINAL 4565A36034 C2600P-1/2H T0.3 1
10 WAX VASELINE 2291140301 VASELINE 0.002
11 CORD POWER 3621302500 250V16A H05VVF 75 1
12 SCREW TAPPING 7121301011 T2S PAN 3X10 MFZN 1
13 SUPPORTER TERMINAL 3625300500 PP(5101SW) 1
14 TERMINAL Y AS 3628716000 TER+WIRE(WH)+RECEPT(187), 250
1
15 TERMINAL Y AS 3628716100 TER+WIRE(BK)+RECEPT(187)+HOU
1
16 SCREW TAPPING 7121400811 T2S PAN 4X8 MFZN 2
17 SHAFT CR 3624901900 PC(LEXAN 500) 1
18 SPRING AS 3625109920 SPRING(4.3M)+ COVER(PP) 1
19 SCREW TAPPING 7121300811 T2S PAN 3X8 MFZN 2
20 SCREW TAPPING 7121401411 T2S PAN 4X14 MFZN 1
23
