Loc. Part Code Part Name Description Remark
L520 5LX159P829 COIL BEAD 1.5UH MIN
L530 5CPZ101K02 COIL PEAKING 100 UH K (AXIAL 3.5 MM)
L540 5LX159P829 COIL BEAD 1.5UH MIN
Q501 KZTA1504-- TR CHIP KTA1504
Q502 KZTA1266Y- TR KTA1266
Q503 TKTD2058Y- TR 2SD2058
R501 RD-2Y229J- R CARBON FILM 1/2W 2.2 OHM J
R502 RD-2Y229J- R CARBON FILM 1/2W 2.2 OHM J
X501 5PQZTT1693 RESONATOR CERA QTTT16.93MMX(3PIN)
Loc. Part Code Part Name Description Remark
9CD6596100 PCB POWER 120X110X1.6T RL-412/412G Only
9CD6595700 PCB POWER 120X110X1.6T RL-411/411G Only
CE903 CEXF1E102V C ELECTRO 25V 1000/25MF (10X22) with PSM Only
CE906 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
CE907 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C901 CCZF1H104Z C CERA HIKF 50V 0.1MF Z (AXIAL) with PSM Only
C902 CCZF1H104Z C CERA HIKF 50V 0.1MF Z (AXIAL) with PSM Only
C903 CCZF1H104Z C CERA HIKF 50V 0.1MF Z (AXIAL) with PSM Only
C904 CCZF1H104Z C CERA HIKF 50V 0.1MF Z (AXIAL) with PSM Only
CM910 CMXM2A223J C MAYLER 100V 0.022UF J
CM911 CMXM2A223J C MAYLER 100V 0.022UF J
9728827100 CONN WAFER TJC3-8A (P=2.5 8P) with PSM Only
9728827300 CONN WAFER TJC3-6A (P=2.5 6P) without PSM Only
9736912200 AC CORD CE
9736912300 AC CORD AMERICA
9736912400 AC CORD BS
9736912500 AC CORD SAA
9736912600 AC CORD Argentina
9736912700 AC CORD DUAL Voltage
D901 DKN4001A-- DIODE 1N4001 with PSM Only
D910 DKN4001A-- DIODE 1N4001 with PSM Only
D911 DKN4001A-- DIODE 1N4001 with PSM Only
D912 DKN4001A-- DIODE 1N4001 with PSM Only
D913 DKN4001A-- DIODE 1N4001 with PSM Only
D914 DKN4001A-- DIODE 1N4001 with PSM Only
D920 DKN4001A-- DIODE 1N4001
D921 DKN4001A-- DIODE 1N4001
D922 DKN4001A-- DIODE 1N4001
D923 DKN4001A-- DIODE 1N4001
D930 --- DIODE TVS1.5KE
5FSGB3112L FUSE 250V T315mA EUROPE/DUAL, RL-411/411G
5FSGB4012L FUSE 250V T400mA EUROPE/DUAL, RL-412/412G
5FSGB5012L FUSE 250V T500mA AMERICA/DUAL, RL-411/411G
5FSGB8012L FUSE 250V T800mA AMERICA/DUAL, RL-412/412G
FC901 9734600700 CLIP-FUSE FC-5N EUROPE/DUAL
FC902 9734600700 CLIP-FUSE FC-5N EUROPE/DUAL
FC903 9734600700 CLIP-FUSE FC-5N AMERICA/DUAL
FC904 9734600700 CLIP-FUSE FC-5N AMERICA/DUAL
C905 CCXF1H104Z C CERA 50V F 0.1MF Z
HC912 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
HC913 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
HC950 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608 with PSM Only
HC951 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608 with PSM Only
HR903 HRFT103JBA R-CHIP 1/10 10K OHM J 1608 with PSM Only
HR904 HRFT103JBA R-CHIP 1/10 10K OHM J 1608 with PSM Only
IC902 1K1A78L05B- IC KIA78L05BP with PSM Only
JW901 W581GY7595 WIRE JUMPER AWG 22 1/0.65 SN7.5 AUTO AMERICA(120V) Only
JW902 W581GY1005 WIRE JUMPER AWG 22 1/0.65 SN10 AUTO without PSM Only
JW903 W581GY7595 WIRE JUMPER AWG 22 1/0.65 SN7.5 AUTO EUROPE(230V) Only
JW904 W581GY1005 WIRE JUMPER AWG 22 1/0.65 SN10 AUTO with PSM Only
F901
F902
PCB POWER ASS'Y [9CDC073000] : RL-412
CW901
CD901
B901
