Loc. Part Code Part Name Description Remark
JW905 W581GY1005 WIRE JUMPER AWG 22 1/0.65 SN10 AUTO without PSM Only
JW906 W581GY1505 WIRE JUMPER AWG 22 1/0.65 SN15 AUTO
JW907 W581GY7595 WIRE JUMPER AWG 22 1/0.65 SN7.5 AUTO
JW908 W581GY1005 WIRE JUMPER AWG 22 1/0.65 SN10 AUTO
PT901 5TP8028829 POWER TRANS PT-SUB PSM Only
5TP8066932 POWER TRANS PT-MAIN RL-412/412G AC220~240V CE
5TP1066933 POWER TRANS PT-MAIN RL-412/412G AC120~127V 60Hz UL
5TP0066934 POWER TRANS PT-MAIN RL-412/412G Dual voltage
5TP0060937 POWER TRANS PT-MAIN RL-411/411G
Q901 TZTC3205Y- TR KTC3205 with PSM Only
R901 RN-2Y475J- R CARBON FILM 4.7M(1/2W) AMERICA(120V) Only
R902 RD-4Z101J- R CARBON FILM 100(1/4W) with PSM Only
R907 RN-1Y4780J RESISTOR MATAL 1W 0.47 OHM J
R908 RN-1Y4780J RESISTOR MATAL 1W 0.47 OHM J
R905 W581GY1505 WIRE JUMPER AWG 22 1/0.65 SN15 AUTO
R906 W581GY1505 WIRE JUMPER AWG 22 1/0.65 SN15 AUTO
RY901 5SC2001A01 SW RELAY SDT-S-105LMR with PSM Only
SW901 5S30102361 SW VOLTAGE SW-3P(SDKHA2) DUAL(230/127V) Only
Loc. Part Code Part Name Description Remark
B401 9CD6595501 PCB AUX IN 49X20X1.6T
CN401 9728826200 CONN AS 3P 1533 130 MM P=2.0 BOARD IN
HC413 HCQK221JBA C CHIP CERA 50V CH 220PF J 1608
HC414 HCQK221JBA C CHIP CERA 50V CH 220PF J 1608
HC415 HCQK221JBA C CHIP CERA 50V CH 220PF J 1608
HC416 HCQK221JBA C CHIP CERA 50V CH 220PF J 1608
HC417 HCQK221JBA C CHIP CERA 50V CH 220PF J 1608
HC418 HCQK221JBA C CHIP CERA 50V CH 220PF J 1608
HR421 HRFT223JBA R-CHIP 1/10 22K OHM J 1608
HR422 HRFT223JBA R-CHIP 1/10 22K OHM J 1608
HR423 HRFT471JBA R-CHIP 1/10 470 OHM J 1608
HR424 HRFT471JBA R-CHIP 1/10 470 OHM J 1608
J402 9766318110 JACK HP HTJ035-13AB GOLD
L420 W581GY1005 WIRE JUMPER AWG 22 1/0.65 AUTO
Loc. Part Code Part Name Description Remark
00010 97C8527400 SPEAKER SYSTEM MS-411RF(5W) RL-411(R)/411G(R) Only
00020 97C8528100 SPEAKER SYSTEM MS-411SF(12.5W) RL-412(R)/412G(R) Only
Loc. Part Code Part Name Description Remark
9CDM057800 REMCOM ASS'Y AM-61M (BASIC) BASIC Model Only
9CDM057900 REMCOM ASS'Y AM-61MR (W/RDS) with RDS Model Only
9CDM058000 REMCOM ASS'Y AM-62M (W/MP3) with MP3 Model Only
9CDM058100 REMCOM ASS'Y AM-62MR (W/RDS, W/MP3) with RDS, MP3 Model Only
00080 9736805700 ANTENNA FM 2M PIG TAIL
00090 9CD6810200 ANTENNA AM LOOP LOOP-7
PCB AUX ASS'Y [9CDC072700] : Front AUX Model only
SPEAKER ASS'Y [9CDM055700] : MS-411
Other
PT903
34000
